| Compaction | Engine | |||||||
| Static linear load | 56/77N/cm | Engine Type | Diesel,aircolled, 1 cylinder | |||||
| Nominal amplitude | 0.5mm | Power | 6.3kw/3600r/m | |||||
| vibration frequency | 65Hz | Fuel tank | 28L | |||||
| Rapid vibration force | 20KN | lubriacting oil | 1.1L | |||||
| water tank | 36L | Fuel cost | 320g/KWH | |||||
| Traveling | Size | |||||||
| Speed | 0-8Km/h | Steel wheel wide | 800mm | |||||
| Turning radius | 1550mm | Steel wheel diameter | 500mm | |||||
| gardeability | 30° | Wheel track | 1320mm | |||||
| General length | 1850mm | |||||||
| working Mode | Gneral wide | 800mm | ||||||
| Driven by hyaulic system/Hydaulic vibration/hydraulic steering | General height | 1500mm | ||||||
| General size | 1950*850*1600mm | |||||||
1. The working radius is small, which can be used in narrow areas, and is suitable for trench backfilling.
2. The high-pressure water spraying system sprays evenly, which can work intermittently and save water. The spray nozzle can be replaced quickly.
3. Moving forward and backward with infinitely variable speed, the vibration button is integrated into the operating handle, which is easy to work. The handle is streamlined and user-friendly, making the operation more comfortable and convenient.
4. With the driving brake function, it can prevent the machine from sliding.
5. The engine adopts domestic well-known brands, which are jointly guaranteed by the whole country. The quality is more guaranteed, and international brands can also be selected.
6. The large variable displacement plunger pump is used to drive the machine to move at an infinitely variable speed. The double motor drives the machine to move. The vibration motor has a stable speed. Press the button once.
